Razorback Utility SWB - Electric UTV 150Ah Lithium
Razorback Utility SWB - Electric UTV 150Ah Lithium
Price excludes GST
Couldn't load pickup availability
Experience the ultimate in convenience and efficiency with The Hawk Razorback SWB Electric Utility Vehicle! This electric vehicle boasts a lithium battery for long-lasting power, 4 wheel hydraulic disc brakes for unmatched safety, and an easy-to-use power steering system. Its sleek design and mag wheels make it both practical and stylish. Upgrade your hauling game today!
Performance
Performance
Maximum Speed: 1-30km/h programable with fast/slow switch
Maximum Travel Distance: 120km
Slope Climbing Capacity: 1 in 3 grade (full load 250kg)
Turning Radius: 2.6m
Power Supply
Power Supply
Battery: 48V 150AH Lithium-ion
Motor: 48V5KW AC - 48Nm
Controller: American Curtis Controller
Accelerator: Non-contact angle sensor accelerator
Charger: RD On-Board Charger 48V 17A - 8hr full charge time
Chassis & Suspension
Chassis & Suspension
Chassis: High Strength Aluminium Structural Main Girder
Front Suspension: Independent A-arm, coil over shocks
Rear Suspension: Semi independent suspension - spring hydraulic cushioning
Steering: Dual direction gear, rack steering system
Braking: 4 Wheel Hydraulic Disc brakes; Auto Park Brake
Dimensions & Weights
Dimensions & Weights
Overall Dimensions LxWxH 2480*1320*1515mm
Wheelbase: 1665mm
Front Wheel Track: 1265mm
Rear Wheel Track: 1275mm
Tyres: 23*10.5-12
Ground Clearance: 330mm
Rear Tray Dimensions LxWxH
800*1100*280mmRear Tray Capacity: 150kgs
Front Tray Dimensions LxWxH 330*1130*90mm
Weight: 395kg (including 65kg battery)
Towing Capacity: ≤1000kgs
Standard Inclusions
Standard Inclusions
- 150Ah Lithium battery
- 4 Wheel Hydraulic Disc Brakes
- Front Nudge Bar
- Rear Balance Bar
- 3 Point Seat Belts
- Auto Park Brake
- Regenerative braking
- Curtis Controller
- On Board Charger
- Full light system including blinkers
- Mag Wheels
- Speedo/Voltmeter/Ammeter
- Tinted Split windscreen
- Reinforced Aluminium Frame
- 12V/USB Outlets
- Reverse Buzzer
- High/Low Speed Switch
- Plastic underbody
Accessories
Accessories
- Front Tray
- Side Rail Guards
- Diff Lock
- Petrol Generator - Range Extender
- Momo Sports Steering Wheel
- Wet Weather Curtains
- Tie Down Points on Rear Tray
- Rhox Stereo sound system
- LED indicator side mirrors
- High back soft seats
- Hanging rack for tools
- LED Roof Mounted Light Bar
- LED Amber Roof Beacon
- Cruise Control
- Rear View Camera
- Winch - Front Mounted
- 6000W Inverter
- Seat Covers - Cool Dry
- 72V System Upgrade
