Hawk Razorback UTV 4WD 48V
Hawk Razorback UTV 4WD 48V
Couldn't load pickup availability
The Hawk Razorback 4WD Utility Task Vehicle has an extended rear tray with an option for electric lift – great for golf course use or around any business associated with landscaping as well as many other diverse uses. The cart comes complete with full digital instrumentation, automatic park brake, 4 wheel hydraulic disc brakes and aluminium chassis.
Performance
Performance
Maximum Speed: 30kmh
Maximum Travel Distance: 80km
Slope Climbing Capacity: 1 in 3 grade (full load)
Turning Radius: 2.6m
Weight: 545kg
Power Supply
Power Supply
Battery: 8V170AH*6
Motor: 48V5KWAC
Controller: American Curtis Controller
Accelerator: Non-contact angle sensor accelerator
Charger: RD Internal Transformer type charger 48V 17A
Suspension
Suspension
Front: Independent-suspension double swing arm system
Rear: Semi independent suspension - spring hydraulic cushioning
Steering: Self compensating rack & pinion, steering double output
Braking: 4 Wheel Hydraulic Disc brakes; Auto Park Brake
Chassis
Chassis
Chassis: High Strength Aluminium Structural Main Girder
Wheel Base: 2400mm
Tyres: 22*10-12 4 Ply
Ground Clearance: 150mm
Standard Inclusions
Standard Inclusions
4Kw AC Motor
4 Wheel Hydraulic Disc Brakes
Auto Park Brake
Regenerative braking
Trojan batteries
Curtis Controller
On Board Charger
Full light system including blinkers
Mag Wheels
Speedo/Voltmeter/Ammeter
Tinted Split windscreen
Aluminium Frame
Plastic underbody
Accessories
Accessories
5kW AC Motor
Petrol Generator - Range Extender
Power steering
Differential Lock
Rear Tray Electric Lift
Mamo Sports Steering Wheel
Wet Weather Curtains
High/Low speed
12V & USB outlets
Hazard Lights
Stabiliser Bar
Side Rail Guards
Rear view mirror
Side mirrors
Steering Lock
Lockable glove box
Tow Hitch
Tie Down Points on Rear Tray
Seat belts
Rhox Stereo sound system
LED Side mirrors
Auto turn off blinkers
High back soft seats
Hanging rack for tools
LED Roof Mounted Driving Lights
Flashing Roof lights – front & rear
Cruise Control
Dimensions
Dimensions
Rear Cargo Dimensions
Width: 1000mm
Length: 1500mm
Height: 300mm
Front Tray Dimensions
Width: 1130mm
Length: 330mm
Height: 90mm
Overall Dimensions
Width: 1320mm
Length: 3400mm
Height: 1830mm
